Powder coating gives engineers and product designers access to a very broad range of colors, gloss levels, textures, metallics, and specialty effects.
That means your sheet metal parts do not have to be limited to basic black, gray, or a standard matte finish. Depending on the application, powder coating can be used to create anything from a simple industrial finish to a bold cosmetic part with metallic, textured, glitter, or color-shifting effects.
Make your powder coated sheet metal parts stand out while still designing around fit, function, coating coverage, masking, and assembly requirements.
Powder Coating vs. Wet Paint
Powder coating and wet paint are both valid finishing options, but they have different strengths.
Powder coating applies a dry powder electrostatically to the metal surface and then cures it to form a continuous coating. Many industrial powder coatings are thermosetting formulations, although thermoplastic powders also exist.
Powder coating can be a strong choice when you need:
- A durable decorative finish
- A broad range of colors
- Different gloss levels and textures
- Metallic or specialty visual effects
- Repeatable production on compatible parts
Wet paint may be preferable for certain applications, including very large parts, temperature-sensitive assemblies, specific paint-system requirements, thin-film applications, or projects where field repair and touch-up are important.
The right choice depends on the substrate, performance requirements, geometry, specification, appearance, and end-use environment rather than one process being universally better than the other.
Creative Powder Coating Options
We often direct customers to Prismatic Powders when they want to explore specialty colors, textures, metallics, and visual effects for custom sheet metal parts.
Prismatic offers thousands of powder options, but availability, cure requirements, substrate compatibility, UV exposure, gloss, texture, and end-use conditions should all be considered before selecting a specialty powder.
Some specialty powders may also affect cost or lead time depending on availability, minimum purchase quantities, application requirements, or whether a multi-stage coating system is required.
These are a few examples of specialty powder categories:
1. Color-Shifting and Effect Powders
Color-shifting, chameleon, metallic, and other effect powders can create finishes that change appearance based on lighting and viewing angle.
These finishes can be useful for highly visible covers, enclosures, displays, branded equipment, automotive components, and other applications where appearance is part of the design.
Because metallic and effect finishes can be sensitive to application technique and viewing angle, an approved sample may be useful when cosmetic consistency is important.
2. Glitter and Decorative Powders
Glitter, sparkle, and other decorative powders can create a much more distinctive appearance than a standard solid-color coating.
These finishes are primarily cosmetic, so engineers should still evaluate the underlying powder system for the required corrosion resistance, UV exposure, durability, and operating environment.
3. Super-Durable Powder Coatings
Some polyester powder formulations are designed for improved exterior weathering and UV retention compared with standard formulations.
These may be useful for parts exposed to sunlight or outdoor environments, but the exact coating system should be selected based on the required specification and service conditions rather than relying on a product-family name alone.
How Specialty Powder Choices Affect Cost and Lead Time
Choosing a nonstandard color does not automatically create a major cost or schedule impact, but specialty powders are not all equivalent from a sourcing or processing standpoint.
Factors that can affect cost or lead time include:
- Whether the powder is already stocked
- Minimum purchase quantities
- Special-order availability
- Metallic or effect formulations
- Multi-coat systems
- Clear-coat requirements
- Special cure requirements
- Low-volume color changes
- Customer approval samples
If color is flexible, a commonly stocked powder may simplify sourcing. If a specific branded or specialty finish is required, identify it during the RFQ so it can be included in the quote and lead-time review.
DFM for Powder Coated Sheet Metal Parts
Powder coating should be considered while the part is being designed, not after fabrication is complete. Coating buildup, hanging, access, masking, grounding, weld appearance, and assembly all influence the finished result.
1. Account for Coating Buildup
Powder coating adds measurable thickness to coated surfaces. The actual film thickness depends on the powder system, specification, application process, part geometry, and finisher.
This can matter for:
- Mating parts
- Tight enclosure fits
- Slots and holes
- Press fits
- Threaded features
- Hardware interfaces
- Gasket surfaces
- Assembly clearances
Engineers should define the required finished-part dimensions and tolerances rather than automatically enlarging every feature to compensate for an assumed coating thickness.
If a surface must remain bare or a feature cannot tolerate coating buildup, identify the masking requirement on the drawing.
2. Design for Hanging and Part Support
Parts generally need to be supported or hung during pretreatment and powder application.
Existing holes, non-cosmetic surfaces, or other features may provide suitable hanging locations. If dedicated hanging features are required, coordinate them with the fabricator rather than automatically adding tabs or holes that may not be necessary.
Hanging locations can also affect where small contact marks appear, so cosmetic surfaces should be identified clearly.
3. Consider the Faraday Cage Effect
Deep recesses, narrow channels, tight inside corners, and enclosed geometry can be more difficult to coat uniformly because of the electrostatic field used during powder application.
This is often called the Faraday cage effect. The electric field can concentrate around exposed edges instead of drawing powder evenly into deep or narrow recesses.
If uniform coating inside a deep pocket or enclosure is functionally important, communicate that requirement early so the geometry and coating process can be reviewed.
4. Consider Sharp Edges and Edge Coverage
Very sharp sheet metal edges can receive less coating thickness than broad flat surfaces.
Rather than applying a universal edge-radius rule, consider the required corrosion protection, cosmetic appearance, edge condition, deburring requirements, and coating specification.
If edge protection is especially important, discuss the requirement with the fabricator and finisher so the appropriate edge preparation and coating system can be evaluated.
5. Provide Drainage and Venting Where Needed
Closed cavities, overlapping seams, tubular components, and poorly drained geometry can trap pretreatment fluids, cleaning solutions, or contaminants during finishing.
Depending on the part and finishing process, tubular or enclosed assemblies may require drain or vent provisions.
This is different from material outgassing, which can occur when trapped gases or contaminants escape from certain substrates during curing.
6. Specify Masking Where Necessary
Some areas may need to remain free of powder coating for functional or dimensional reasons.
Common masking locations include:
- Threads
- Grounding points
- Electrical contacts
- Mating surfaces
- Precision holes
- Bearing or locating surfaces
- Gasket surfaces
- Hardware interfaces
- Cosmetic boundaries
Masking zones should be shown clearly on the drawing rather than left for the fabricator or finisher to assume.
7. Consider Hardware Installation Sequence
Self-clinching hardware, threaded inserts, and other installed hardware can interact with the powder coating process.
Depending on the hardware and application, considerations may include:
- Whether hardware is installed before or after coating
- Protecting threads from coating buildup
- Maintaining bare metal for grounding
- Avoiding coating interference with hardware installation
- Protecting cosmetic hardware surfaces
The correct sequence depends on the specific hardware, material, finish, and functional requirements, so identify the exact hardware part number and finishing requirements on the drawing.
8. Protect Grounding and Electrical Contact Areas
Powder coating is generally electrically insulating.
If a sheet metal enclosure or assembly requires grounding, bonding, or electrical continuity, the design may need specified bare-metal contact areas or masking.
Do not assume that a screw, washer, or fastener will reliably break through the coating and create the required electrical connection.
Grounding locations should be identified explicitly on the drawing so the coating and assembly process can support the electrical requirement.
9. Plan for Welds and Cosmetic Surfaces
Powder coating does not replace proper surface preparation.
Weld spatter, grinding marks, scratches, oil, contamination, and inconsistent weld finishing may remain visible through the final coating depending on the powder color, gloss, texture, and cosmetic requirement.
If appearance is important:
- Identify cosmetic surfaces on the drawing
- Specify the required weld finish
- Provide access for grinding or blending where required
- Avoid unnecessary crevices that can trap contaminants
- Define acceptable cosmetic standards when appearance is critical
High-gloss and smooth finishes may reveal surface variation differently than textured or lower-gloss coatings, so finish selection and fabrication quality should be considered together.
How to Specify Powder Coating on a Drawing
Simply calling out “powder coat black” may not provide enough information when color or appearance matters.
Depending on the project, specify:
- Powder manufacturer and product number, if required
- Color or applicable RAL reference
- Gloss level
- Texture
- Applicable coating specification
- Masking requirements
- Grounding or conductive contact areas
- Surfaces that must remain uncoated
- Cosmetic surfaces
- Finished dimensional requirements
- Approved sample or color standard, when required
A RAL number can be useful for communicating color, but color alone does not define the complete powder coating system. Two powders with similar colors can have different gloss, texture, chemistry, durability, and appearance.
If you would like help selecting or specifying a powder coating for your custom sheet metal parts, send the finish requirements with your design. When you’re ready to get your project moving, request a quote and include your 3D CAD model, drawing, quantity, and powder coating requirements.
6 Tips for Designing Powder Coated Sheet Metal Parts
POWDER COATING
With over two decades of experience in powder coating, we’ve learned that a little bit of foresight yields superior outcomes. Here are our top tips for powder coated sheet metal parts.
Read the 6 TipsPowder Coated Sheet Metal Parts FAQ
How does powder coating differ from traditional paint for sheet metal parts?
Powder coating involves applying dry powder electrostatically, creating a durable finish compared to the multi-coat process of traditional wet paint. It’s quicker and offers a wider range of vibrant colors and textures.
What are the advantages of using Prismatic Powders for customizing sheet metal parts?
Prismatic Powders offer a vast selection of colors and textures, including color-shifting, disco-themed sparkles, and super durable options. While some may have premium pricing, these top-quality coatings provide endless creative possibilities.
Can I choose unconventional colors without affecting lead times or costs?
Absolutely! Opting for bold or unique colors in powder coating won’t significantly impact time or costs. The extensive range of available colors doesn’t add to lead times or drastically inflate expenses for sheet metal projects.
How does powder coating speed up the finishing process for metal parts?
Compared to the lengthy process of priming, painting, and waiting for each coat to dry, powder coating cuts down on time significantly. What might take two weeks with wet paint could be accomplished in half the time or less with powder coating.
Can I receive assistance in selecting the perfect powder coating for my project?
Absolutely! We love exploring options with our customers. If you’re seeking assistance in customizing your sheet metal parts with vibrant and unique colors, reach out to us. Request a quote, and we’ll help you find the perfect coating for your project.
