Have you ever noticed that standard tolerancing in precision sheet metal fabrication is not as straightforward as in precision machining?
Sheet metal tolerancing is more complicated because the achievable tolerance depends on the raw material, the feature being measured, and the manufacturing processes used to create the part. A dimension between two laser-cut holes on the same flat surface, for example, can typically be controlled much more tightly than a dimension that crosses several bends.
Understanding those differences helps engineers specify tolerances that protect fit and function without adding unnecessary manufacturing cost.
Raw materials
Traditional machining projects generally begin with a solid piece of material, such as bar stock or round stock. In precision sheet metal fabrication, our material is supplied in sheets.
Sheet metal gauge represents a nominal thickness, but the actual material thickness can vary within the allowable range for that material specification. That variation matters when tight tolerances are applied to a fabricated part.
For example, 16 gauge cold-rolled steel has a nominal thickness of approximately 0.060″, but actual thickness can vary depending on the material specification and mill tolerance. When a part also includes bends, formed features, welding, or other fabrication processes, those variations can contribute to the final dimensional result.
This is one reason it is important to distinguish between dimensions that are truly critical to the function of the part and dimensions that can use normal fabrication tolerances.
Manufacturing processes
The other major factor is the manufacturing process used to create a specific feature. Different fabrication operations have different tolerancing capabilities.
If features are located on the same flat surface, we can reliably achieve typical tolerances of +/- 0.005″ because the equipment we use, typically a punch press or laser, can position and cut those features very accurately.
However, once we add formed features to the part, such as flanges, additional variation must be considered.
A flange is positioned against a press brake back gauge, and a punch and die are used to create the bend. During forming, the material stretches on the outside of the bend and compresses on the inside. Material thickness, bend radius, tooling, grain direction, springback, and normal material variation can all affect the final position of the formed feature.
For that reason, at Approved Sheet Metal we typically account for approximately +/- 0.010″ for a bend-to-edge dimension.
As we add more formed features, tolerance can continue to accumulate. We typically account for approximately +/- 0.020″ bend to bend, with cumulative tolerances of up to approximately +/- 0.030″ on parts containing multiple formed features.
These values are general fabrication guidelines rather than universal tolerances for every sheet metal part. Material, thickness, geometry, tooling access, bend sequence, welding, hardware, finishing, and drawing requirements can all affect what is achievable.
What Are Typical Precision Sheet Metal Tolerances?
There is no single tolerance that applies to every dimension on a fabricated sheet metal part. The appropriate tolerance depends heavily on how the feature is manufactured and where it is located on the finished part.
| Feature or Dimension | Typical Tolerance | Primary Considerations |
|---|---|---|
| Features on the same flat surface | +/- 0.005″ | Laser or punch accuracy, material, feature geometry |
| Bend to edge | +/- 0.010″ | Material thickness, bend angle, springback, tooling |
| Bend to bend | +/- 0.020″ | Multiple forming operations and accumulated variation |
| Multiple formed features | Up to approximately +/- 0.030″ | Number of bends, bend sequence, geometry, and material behavior |
| Tighter critical dimensions | Application dependent | May require secondary machining, special tooling, fixtures, or additional inspection |
These are typical Approved Sheet Metal fabrication guidelines. The drawing requirements and specific geometry of each part still need to be reviewed before manufacturing.
Sheet Metal Part Design for Manufacturing Tip
DESIGNING FEATURES TOO CLOSE TO THE BEND
Standard press brake tooling requires that any feature be 3-4x the material thickness away from the edge of a bend. Anything under that will deform or pull the material, stretching and causing the feature to not be useable or functional in the end product.
Get more DFM TipsA Note on Tolerance Stack-Ups
At Approved Sheet Metal, our team has decades of experience designing and making precision sheet metal parts. An important part of that experience is understanding where dimensional variation can accumulate before it creates an assembly problem.
A tolerance stack-up occurs when variation from several individual dimensions or manufacturing operations combines into a larger overall variation.
For example, a dimension measured from a cut edge to the first bend is generally easier to control than a dimension that crosses three or four separate bends. Each forming operation can introduce additional variation, so dimensions that span multiple formed surfaces require more tolerance than features located on the same flat surface.
When several holes, panels, fasteners, or other features must align in an assembly, we look at the complete tolerance stack rather than evaluating each dimension independently.
Typically, we can anticipate and mitigate tolerance stack-up issues before they arise. However, if stack-ups become a concern, there are several manufacturing and design options available.
For example, for a welded enclosure with a cover, we might recommend using a PEM® floating fastener. A floating fastener provides additional positional allowance between mating components, helping accommodate normal fabrication variation.
Another option is to completely form the part and then perform a secondary machining operation on a critical hole, bore, surface, or other feature. This approach can provide tighter control after forming, but the additional machine time also increases manufacturing cost and lead time.
Can Precision Sheet Metal Hold +/- 0.005″ Tolerances?
Yes, on the right features.
Features cut or punched into the same flat surface can often be held to +/- 0.005″. However, that does not mean +/- 0.005″ should be applied to every dimension on a formed sheet metal part.
Dimensions involving bends, several formed surfaces, welded components, installed hardware, or assemblies generally need additional tolerance.
If a +/- 0.005″ dimension must be maintained after forming, the fabricator should review the requirement before production. Depending on the geometry, it may require a different manufacturing sequence, secondary machining, special tooling, fixturing, or additional inspection.
How Do Multiple Bends Affect Sheet Metal Tolerances?
Each bend introduces another opportunity for dimensional variation.
Material thickness, hardness, grain direction, springback, tooling, bend angle, and part geometry can all slightly affect the final position of a flange. When a dimension crosses several bends, those individual variations can accumulate.
This is why bend-to-bend dimensions generally require more tolerance than dimensions between two features cut into the same flat surface.
For parts with several formed surfaces, engineers should identify the dimensions that actually control fit and function rather than applying the tightest possible tolerance to every dimension.
How Close Can a Hole or Feature Be to a Bend?
As a general DFM guideline, holes, slots, and other cut features should be kept approximately 3 to 4 times the material thickness away from the edge of a bend when possible.
When a feature is located too close to a bend, the forming operation can stretch or pull the surrounding material. This may cause holes to become distorted, slots to change shape, or other features to move enough that they no longer function as intended.
The exact minimum distance depends on the material thickness, bend radius, tooling, feature size, and feature orientation.
If a critical hole, slot, or other functional feature needs to be located close to a bend, it is best to have the design reviewed by the fabricator before production.
How Does Welding Affect Sheet Metal Tolerances?
Welding introduces heat into a sheet metal assembly, which can cause localized expansion, contraction, and distortion.
The amount of movement depends on factors including the material, material thickness, weld size, weld length, joint design, weld sequence, and fixture design.
For that reason, dimensions across a welded assembly generally need to account for more variation than dimensions contained within a single laser-cut or formed component.
Fixtures, controlled weld sequencing, intermittent welds, design changes, and post-weld machining can all be used when tighter assembly dimensions are required.
When Does a Sheet Metal Part Need Secondary Machining?
Secondary machining can be used when a critical feature requires tighter positional or dimensional control than the normal cutting and forming process can reliably provide.
For example, a sheet metal part may be laser cut and completely formed before a critical hole, bore, mounting surface, or other feature is machined to its final dimension.
This allows the machining operation to establish the critical feature after the normal variation from forming has already occurred.
Secondary machining is useful for the right application, but it adds another manufacturing operation, additional setup, and machine time. It is generally best reserved for dimensions that directly affect fit, alignment, sealing, or the function of the finished assembly.
How Should Engineers Specify Sheet Metal Tolerances?
The best approach is to identify which dimensions are actually critical to the function of the finished part.
Before applying a tight tolerance, consider:
- Which holes need to align with mating components?
- Which surfaces locate the part within an assembly?
- Which dimensions affect clearance or interference?
- Which dimensions cross one or more bends?
- Which features need to align after welding?
- Which dimensions can safely use standard fabrication tolerances?
Applying tight tolerances only where they are functionally necessary generally creates a more manufacturable and cost-effective part.
Unnecessarily tight tolerances may require additional inspection, special tooling, secondary machining, fixtures, or slower manufacturing processes without improving the performance of the finished assembly.
When a tolerance is particularly important, identifying the functional requirement on the drawing can also help the fabricator recommend the most practical manufacturing approach.
