Aluminum Smackdown: 5052-H32 Takes on 6061-T6 for Custom Sheet Metal Fabrication Superiority (Updated for 2026)

Last updated on January 7th, 2026 at 11:27 am

If you’re accustomed to selecting 6061-T6 aluminum for machining, you may find yourself automatically requesting that same material for your sheet metal parts. But 6061 aluminum isn’t typically the best choice for a sheet metal part. For aluminum fabrication, we usually recommend 5052-H32 instead.

Here, we’ll outline the differences between 6061 and 5052 and explain why 5052 is the superior choice for sheet metal fabrication.

Which Alloy Is Best for Sheet Metal Fabrication?

Although both 5052-H32 and 6061-T6 aluminum are lightweight, strong, and corrosion resistant, they serve different purposes in fabrication. For most sheet metal parts, especially those requiring tight bends, welding, and formability, 5052-H32 is the superior choice. In contrast, 6061-T6 excels in machined or structural components where high strength and surface finish are priorities but extensive forming is limited. This distinction is key when designing parts for fabrication versus machining.

Key Differences Between 6061-T6 vs. 5052-H32 Aluminum

While both aluminum alloys are lightweight, strong, corrosion-resistant, and weldable (with some potential for heat deformation), the two materials are not interchangeable.

Property	5052-H32	6061-T6
Formability	Excellent – ideal for bends and formed features	Fair – prone to cracking without larger radii or softening
Weldability	Very Good – excellent for welded seams	Good – heat-affected zone can reduce strength
Fatigue Strength	Higher – resists cyclic stress better	Lower – stronger but less elastic under repeated load
Machinability	Lower – softer material may gum up tools	Excellent – easy to machine with tight tolerances
Corrosion Resistance	Excellent – performs well in marine environments	Good – resists corrosion but less than 5052
Cost	Lower – generally more cost-effective	Higher – more expensive per pound

Why Temper Matters as Much as the Alloy

In aluminum selection, the temper (such as H32 or T6) affects material performance just as much as the underlying alloy. Temper describes how the metal is processed, through cold work or heat treatment, which alters its strength, ductility, and formability. For example, 5052-H32 maintains good elasticity and fatigue resistance without heat treatment, making it easier to form without cracking. In contrast, 6061-T6 is heat-treated for high strength but has less ductility, so it may crack at tight bend radii unless softened or post-processed. Understanding both alloy and temper ensures parts behave predictably in fabrication.

Choose 6061-T6 for machined parts

6061-T6 aluminum is heat-treated and very hard, so it machines beautifully!

However, 6061 does not play well with forming processes, as the alloy is highly likely to crack when formed to 90 degrees or beyond. If you must have a 6061 aluminum part with a 90-degree bend, we recommend making the internal radii equal to at least 2x to 3x the material thickness.

Cosmetic issues such as scratches and dents are also considerations when using 6061-T6 for aluminum fabrication. These cosmetic concerns can be managed, but be aware that fixing surface blemishes may increase both cost and lead time.

The properties of 6061-T6 aluminum include:

• Yield strength: 241 MPa (35,000 psi)
• Ultimate tensile strength: 290 MPa (42,000 psi)
• Primary alloying elements: magnesium and silicon

Common applications for 6061-T6 include:

• Aerospace
• Aircraft
• Bridges
• Rivets
• Train cars
• Towers
• Transportation operations
• Vehicle frames

Sheet Metal Design for Manufacturing

FREE eBOOK DOWNLOAD

Design parts with the sheet metal fabrication process in mind. Reduce cost and get parts on your desk faster! Learn about the following best practices when designing sheet metal parts:

• Hems & Offsets
• Notches & Tabs
• Corners & Welding
• Uniform Thickness and more!

Get it now

5052-H32 Versus 6061-T6 for Sheet Metal Fabrication FAQ

What are the key differences between 6061-T6 and 5052-H32 aluminum for sheet metal fabrication?

5052-H32 is more formable and fatigue-resistant, while 6061-T6 is stronger and better for machining.</strong> 5052’s ductility and weldability make it ideal for formed parts, whereas 6061’s heat-treated strength is suited for machined or structural components.

Why is 5052-H32 preferred over 6061-T6 for fabricated parts?

5052-H32 offers better formability without the risk of cracking during fabrication, making it an ideal choice for parts requiring tight radii or extensive forming. Additionally, its cost-effectiveness at approximately $2 less per pound than 6061 aluminum adds to its appeal for fabricated parts.

What are the primary considerations when choosing between 6061-T6 and 5052-H32 for aluminum fabrication?

For 6061-T6, its strength and machinability are notable, but potential cracking, cosmetic issues, and the need for larger bend radii are crucial considerations. Conversely, 5052-H32’s formability, smoother surface finishes, and cost-effectiveness make it a preferable choice for fabricated parts.

Are there specific applications where 6061-T6 or 5052-H32 excel over the other?

6061-T6 finds use in aerospace, bridges, transportation, and structural applications due to its strength, while 5052-H32 is favored for panels, enclosures, marine equipment, and medical devices where forming requirements are critical.

What should be done when 6061-T6 is the specified material but concerns exist about its fabrication suitability?

In cases where 6061-T6 is specified but tight radii or extensive forming is necessary, it’s advisable to discuss a material swap to 5052-H32 with the fabricator. Approved Sheet Metal typically recommends this change to ensure better quality and prevent potential complications during fabrication.
